MASW / VS30 Shear Wave Velocity Testing in Fontana, California

Q: What is the typical cost of a MASW survey for a commercial lot in Fontana?

The final cost is always scoped in a fixed-fee proposal after reviewing the site plan.

In Fontana we often encounter a distinct velocity contrast at relatively shallow depths — alluvial fan deposits from the San Gabriel Mountains overlying older Tertiary sediments, with the Sierra Madre Fault Zone just to the north. This geological setting means that a generic VS30 value from a regional map won't capture the real seismic response of your site. We deploy active-source MASW with 24-channel seismographs and 4.5 Hz geophones, processed through dispersion curve inversion, to deliver a measured shear wave velocity profile tied directly to ASCE 7-22 Site Class. For sites with deep bedrock, we supplement the surface wave data with a targeted SPT drilling campaign to correlate N-values with velocity at depth, ensuring the profile is defensible for the reviewing structural engineer.

A measured VS30 of 360 m/s versus a default 260 m/s can reduce base shear demand by 20 percent — that's the difference between a mat foundation and a deep pile system.

How we work

The difference between a site near the Kaiser Steel legacy area and one up against the Jurupa Hills in northern Fontana can be a full site-class jump, from D to C. Our field methodology accounts for this spatial variability. We set up survey lines no shorter than 115 ft and use multiple shot points to evaluate lateral homogeneity before accepting a dispersion curve. The inversion process is constrained with a priori geologic data — when available, we tie the velocity model to test pit logs for the upper 15 ft, removing the non-uniqueness that plagues unconstrained inversions. The final deliverable includes the time-averaged VS30, the VS profile to 100 ft (or to refusal), and the NEHRP site class per IBC Table 1613.2.3. For critical structures, we also report the site period and amplification factors.

Local geotechnical context

Fontana's building stock expanded rapidly during the post-war decades, well before the 1997 UBC adoption of site-specific seismic provisions. Many older commercial buildings on Sierra Avenue were designed with a default Site Class D assumption — which can be unconservative if the site sits on soft alluvium that actually classifies as Site Class E. We've profiled parcels where the VS30 dips below 500 ft/s, triggering the special seismic provisions of ASCE 7-22 Section 11.4.8. The consequence of misclassification is not abstract: a site period shift can align structural response with the 1–2 second spectral peak of a San Andreas event, increasing drift demands beyond what the lateral system was designed to handle. A single MASW survey run before schematic design eliminates this uncertainty entirely.

Technical parameters

Parameter	Typical value
Test Standard	ASTM D4428/D4428M-14 (active MASW)
Survey Line Length	115–230 ft (35–70 m), site-dependent
Geophone Frequency	4.5 Hz vertical-component, 24-channel spread
Maximum Profiling Depth	100–130 ft (30–40 m), soil-dependent
Analysis Method	Dispersion curve inversion, fundamental mode
Primary Output	VS30, VS100, NEHRP Site Class A–F
Source Type	10–20 lb sledgehammer with trigger switch
Site Period (T0)	Per ASCE 7-22 Section 11.4.8, computed from VS profile

Other technical services

Single-Line MASW Survey

One 115-ft spread with center and off-end shots. Suitable for single-family residential or small commercial pads needing IBC site class confirmation.

Multi-Line 2D Velocity Mapping

Two or three intersecting survey lines across the building footprint. Used when lateral variability is expected — common near the alluvial fan margins in north Fontana.

MASW + Downhole Seismic Combination

Surface MASW calibrated with a downhole survey in a cased borehole. Required for sites where a definitive VS profile to 100 ft is mandated by the geotechnical reviewer.

Seismic Site Classification Report

Stand-alone report with VS30 calculation, site period, and seismic design parameters (SDS, SD1) per CBC Chapter 16. Includes signed digital data files for the structural engineer.

Applicable standards

ASTM D4428/D4428M-14: Standard Test Methods for Crosshole Seismic Testing (adapted for surface MASW), ASCE/SEI 7-22: Minimum Design Loads and Associated Criteria for Buildings and Other Structures, IBC 2021 (California adoption): Chapter 16, Structural Design — Section 1613.2, NEHRP Recommended Seismic Provisions: Site Classification Procedure

Quick answers

Does the City of Fontana require a measured VS30 for building permits?

The City of Fontana Building & Safety Division enforces the California Building Code, which defers to ASCE 7 for seismic site classification. If the geotechnical report uses a measured VS30 to justify a Site Class other than the default D, the Building Official will expect the MASW data to be included in the project file. For Risk Category III and IV structures, a measured VS profile is essentially standard practice.

What is the typical cost of a MASW survey for a commercial lot in Fontana?

How long does it take to get the VS30 report after fieldwork?

Field acquisition typically takes two to three hours for a single-line survey. The dispersion analysis, inversion, and reporting is a three to four business day process. If you need preliminary VS30 and site class for a submittal deadline, we can often provide a draft data sheet within 48 hours of the survey.
